3-Lamp Injection Molding LED Module – DC12V SMD 5050 Waterproof Backlight for Channel Letters & Signs

Product Description

Illuminate your signage with precision and reliability using the 3-Lamp Injection Molding LED Module, engineered for professional backlighting applications. Designed for advertisement signs, channel letters, light boxes, and other illuminated displays, each module delivers bright, energy-efficient light output through three high-performance SMD 5050 LEDs.

Built for durability and outdoor performance, these modules feature IP65 waterproof protection, ensuring consistent brightness in all weather conditions. With a wide 140° beam angle, they provide uniform illumination, eliminating dark spots for crisp, clean signage lighting. Constructed with a glass fiber circuit board, this module guarantees long-lasting stability and heat resistance—ideal for commercial, architectural, or decorative use.

Key Features

💡 High Brightness Output – 3 SMD 5050 LED chips provide 15–18 lumens per bead for vibrant illumination.

🏗️ Professional-Grade Build – Injection-molded housing and glass fiber board ensure durability and long service life.

🌧️ IP65 Waterproof Design – Resistant to rain, dust, and moisture for both indoor and outdoor installations.

🌈 Wide Beam Angle – ≥140° coverage provides even lighting for signs, logos, and advertisements.

⚡ Low Voltage & Energy Efficient – Operates safely at DC12V with only 0.72W per module.

🔧 Versatile Application – Ideal for commercial signage, light boxes, channel letters, displays, and architectural accents.

Product Specifications

• Product Type: LED Backlight Module

• Model: 3-Lamp Injection Molding Module

• Operating Voltage: DC12V

• LED Type: SMD 5050

• Luminous Flux: 15–18LM per LED

• Number of LEDs per Module: 3 LEDs

• Power Consumption: 0.72W per Module

• Beam Angle: ≥140°

• Dimensions: 2.56" × 0.63" × 0.16" per module

• Circuit Board Material: Glass Fiber

• Waterproof Rating: IP65

• Color Options: White (without remote control)

• Connection: Interface at Both Ends

• Compatibility: DC12V Power Supply (Not Included)

• Installation: Professional Installation Recommended

Package Details

• 1 × 3-Lamp LED Module (Module Only – No Remote or Power Supply Included)

Care & Notice

• For professional installation only—improper wiring may damage components.

• Use with a DC12V regulated power supply.

• Do not submerge in water; IP65 waterproof for splash and weather protection only.

• Not shipped on weekends.

• Ideal for advertisement lighting, channel letters, display cases, boats, RVs, or architectural accents.
